0.2mm Thickness *25MM*25MM Mesh Steel Round Perforated Metal Mesh
1. Perforated Metal, also called filter sheet, sound insulation sheet, sieve sheet.
2. Feature: Wide usages, good look.
3. Material: Hot-rolled and cold-rolled carbon steel sheets, galvanized steel sheets, stainless
Steel sheets, aluminum, aluminium-alloy, aluminum-plastic, copper, nickel, titanium,PVC and other sheet materials
4. Hole pattern: Round, oval, square, rectangular, rhombus, hexagon, scale,Shape and composition of different shapes, also other special shapes.
5. Measures Standard:
1)Sheet size: 1M x 2M, 0.915M x 2.44M (3 'x 8'),
1.22M x 2.44M (4 'x 8'), 0.915M x 3.05M (3 'x 10'), 1.22M x 3.05M (4 'x 10').
Available in size 26 to 1 / 2 "in Stainless Steel or in carbon steel.
2)Roll size: 1m x 20m
6. Workmanship: Stamping
7. Production Process: Stamping, leveling, cutting, bending, reeling, welding, shaping and Surface treatment.
8. Chracteristics: Light weight, Bend-resisting, aging-resisting, not easily to rust, Wide uses
0.2mm Thickness *25MM*25MM Mesh Steel Round Perforated Metal Mesh
Perforated Metal Mesh Product Specification
Materials: Hot-rolled and cold-rolled carbon steel sheets, galvanized sheets, stainless steel sheets, aluminum, aluminum-plastic, copper, nickel, titanium, PVC and other sheet materials.
Opening: Round, oval, square, rectangular, rhombus, hexagon, scale shape and composition of different shapes, also other special shape.
Process: Stamping, leveling, cutting, bending, reeling, welding, shaping and surface treatment.
Application: Mine, machinery, food, stationery and sports goods, kitchen and toilet supplies, muffler, decoration, cons.
Perforated Metal Mesh Specification
| Hole | Hole | Pitch | Number of Hole | Open Area |
| In. No. | In MM | In MM | Per Sq.Inch | In % |
| 3.00 | 0.50 | 1.09 | 627.02 | 19.09 |
| 3.25 | 0.55 | 1.25 | 476.00 | 17.50 |
| 3.50 | 0.60 | 1.25 | 471.00 | 20.90 |
| 3.75 | 0.70 | 1.35 | 408.00 | 24.39 |
| 4.00 | 0.80 | 1.39 | 385.57 | 30.05 |
| 4.50 | 0.90 | 1.39 | 385.57 | 38.04 |
| 5.00 | 1.00 | 1.67 | 267.12 | 32.53 |
| 5.25 | 1.10 | 1.67 | 267.12 | 39.36 |
| 5.50 | 1.20 | 2.00 | 186.24 | 32.66 |
| 5.75 | 1.30 | 2.25 | 147.15 | 30.29 |
| 6.00 | 1.40 | 2.50 | 119.19 | 28.45 |
| 6.25 | 1.50 | 3.00 | 82.77 | 22.68 |
| 6.50 | 1.60 | 3.17 | 74.13 | 23.11 |
| 6.75 | 1.70 | 3.25 | 70.53 | 24.82 |
| 7.00 | 1.80 | 3.50 | 60.81 | 24.00 |
| 7.25 | 1.90 | 3.50 | 60.81 | 26.74 |
| 7.50 | 2.00 | 3.75 | 52.98 | 25.81 |
| 7.75 | 2.10 | 3.75 | 52.98 | 28.45 |
| 8.00 | 2.20 | 4.33 | 39.73 | 23.42 |
| 8.25 | 2.30 | 3.50 | 60.81 | 39.18 |
| 8.50 | 2.40 | 3.50 | 60.81 | 42.66 |
| 8.75 | 2.50 | 5.00 | 29.80 | 22.68 |
| 9.00 | 3.00 | 5.00 | 29.80 | 32.66 |
| 10.00 | 3.20 | 6.50 | 17.63 | 21.99 |
| 10.25 | 3.50 | 6.50 | 17.63 | 26.31 |
| 10.75 | 4.00 | 6.50 | 17.63 | 34.36 |
| 11.25 | 4.50 | 6.50 | 17.63 | 43.48 |
| 11.75 | 5.00 | 8.00 | 11.64 | 35.44 |
| 12.50 | 6.00 | 8.00 | 11.64 | 51.03 |
| 12.50 | 6.00 | 9.00 | 9.20 | 40.32 |
| 13.75 | 7.00 | 11.25 | 5.89 | 35.13 |
| 15.00 | 8.00 | 11.25 | 5.86 | 54.88 |
| 15.75 | 10.00 | 15.00 | 3.31 | 40.32 |
| | 12.00 | 18.00 | 2.30 | 40.32 |
| OTHERS |
| | 2.00 | 4.91 | 30.90 | 15.05 |
| | 2.50 | 5.20 | 27.55 | 20.97 |
| | 3.00 | 4.75 | 33.02 | 36.19 |
| | 4.00 | 6.00 | 20.69 | 40.32 |
| | 5.00 | 7.80 | 12.24 | 37.28 |
| | 6.00 | 7.80 | 12.24 | 53.68 |
| | 8.00 | 10.50 | 6.76 | 52.67 |
Product Tags:
|
|
Steel Round Perforated Metal Mesh 0.2mm Thickness *25MM*25MM Size Images
|
