16 Mesh*18 Mesh Mosquito Protection Galvanized And Fiberglass Window Screens
Galvanized blue finishing iron window screen Introduction
Galvanized window screen
1.Popular window screen
2.Cheap window screen
3.Mesh:6x6 10X10 14X14 16X16 etc.
Stainless steel window screen
Material:S/S 202,430,SUS 304,316
Plain Weaving
Mesh:10x10,11x11,12x12,14x14,16x16,18x18,20x20
width 2'' to 6''
Aluminum alloy window screen
Mesh: 18x16, 18x14, 14x14
Diameter: 0.22mm, 0.23mm, 0.25mm, 0.27mm, 0.38mm, 0.40mm
Color: bright(nature color), silver(painted), charcoal, black, brown
Width: 2feet, 2.5feet, 3feet, 3.5feet, 4feet, 5feet
Length: 100 feet, 300feet maximum
| Classification: | Stainless Steel Window Screen Fibreglass Window Screen PVC Coated Window Screen Powder Coated Window Screen Galvanized Window Screen Aluminum Window Screen Expoxy Coated Wire Mesh |
| Mesh Available: | 10*12mesh, 12*12mesh, 12*14mesh, 14*14mesh, 14*16mesh, 14*18mesh, 16*16mesh, 16*18mesh, 18*18mesh, 18*20mesh, 20*20mesh |
| Wire Diameter: | from 0.5mm to 0.45mm |
| Aperture: | 3'x100', 4'x100', 1x25m,1.2x30m,1.5x25m |
| Material: | stainless steel, aluminum, galvanized wire, fibre glass etc. |
| Surface treatment: | Epoxy coated, powder coated, PVC coated, Polished |
| Color: | white, black, grey, charcoal, bright, brown, green etc. |
| Edge: | locked edge, selvaged edge, non-selvaged edge, fold edge |
| NOTE: | Special Sizes and Colors are available to customize according to the customers' requirement |
| Specification List of Window Screen Netting |
| Variety | Specification | Technical Notes |
| Mesh/Inch | Wire Gauge | Roll Size |
| Gal.Iron Enamelled Window Screening | 10 x 10 | BWG31
BWG32
BWG33
BWG34 | | 3"x100" | | 4"x100" | | 1x25M | | 1.2x30M | | 1.5x25M | | Process: Electric galvanized after weaving
Color: White or Light-blue |
| 14 x 14 |
| 16 x 16 |
| 18 x 18 |
| 18 x 14 |
| 22 x 22 |
| 24 x 24 |
| Aluminum Wire Window Screening | 10 x 10 | BWG31
BWG32
BWG33
BWG34 | 3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M | Material: Al-mg.alloy or Enamelled Aluminium Window Screening |
| 14 x 14 |
| 16 x 16 |
| 18 x 18 |
| 18 x 14 |
| 22 x 22 |
| 24 x 24 |
| Fiberglass Window Screening | 10 x 10 | BWG31
BWG32
BWG33
BWG34 | 3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M | Green Or Dark Green |
| 14 x 14 |
| 16 x 16 |
| 18 x 18 |
| 18 x 14 |
| 22 x 22 |
| 24 x 24 |
| Plastic Wire Window Screening | 12x 12 | BWG31
BWG32 | 3"x100"
4"x100"
1x25M
1.2x25M | Twisted weaving:12 14 16mesh;
Plain weaving:18 22 24mesh;
Colors available:white,blue,green,etc. |
| 14 x 14 |
| 16 x 16 |
| 18 x 18 |
| 22 x 22 |
| 24 x 24 |
