PVC Coated Concertina Razor Barbed Wire with 2 . 5 mm Core Wire and 1 m Roll Diameter
Product Introduction
Razor Wire Concertina Wire is also named concertina coils,concertina wires. It is a kind of modern security fencing materials with better protection and fencing strength.
It made by hot-dipped galvanized blade or stainless steel blade, high tensile strength core wire( steel wire with 1200mpa tensile strength or stainless steel wire).
It is a new type of protection fence. With the character of beautiful, economical, secure fencing, construction of facilities, etc.
Product Feature
1. High security
Barbed razor wire with the sharp razor guarantees a high security whilst retaining high quality.
2. Long life
Razor wire material of stainless steel or hot-galvanized makes sure for long life and low maintenance.
3. Easy installation
Short sections needed for urgent security can be installed extremely fast and with little equipment, allowing repairs to be carried out without compromising perimeter security.
Product Application
Protection, prevention, isolation.
Razor wire concertian wire is widely used in industrial, mining enterprises, garden apartment, border posts, military field, prisons, detention center, government buildings and other national securit facilities.
Product Specification
| Reference Type Number | Thickness | Wire Dia. | Barb Length | Barb width | Barb spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 25±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 25±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 35±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 36±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 46±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 46±1 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±1 | 21±1 | 101±2 |
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
| 450 mm | 33 | 8M | CBT-65 | Single Coil |
| 500 mm | 41 | 10 M | CBT-65 | Single Coil |
| 700 mm | 41 | 10 M | CBT-65 | Single Coil |
| 960 mm | 53 | 13 M | CBT-65 | Single Coil |
| 500 mm | 102 | 16 M | BTO-10,15,22 | Cross type |
| 600 mm | 86 | 14 M | BTO-10,15,22 | Cross type |
| 700 mm | 72 | 12 M | BTO-10,15,22 | Cross type |
| 800 mm | 64 | 10 M | BTO-10,15,22 | Cross type |
| 960 mm | 52 | 9 M | BTO-10,15,22 | Cross type |
