4 MM Wire 3 " * 1 / 2 " Hole 2 . 4 M Height 358 Security Wire Mesh Fence
Product of 358 Anti Climb Fence / 358 Mesh Fence:
358 high security fence also known as " prison mesh", this production offers the best value for performance, durability and appearance.
'358' comes from its measurements 3" x 0.5" x 8 gauge which equates to approx. 76.2mm x 12.7mm x 4mm in metric. It is a professional structure designed for high security environments, combined with an steel framework, coated with heavily zinc or RAL color Powder coating.
Material:
Q195, galvanized wire, stainless steel wire.
Surface Treatment:
Galvanized(electro, hot dipped)
PVC spraying,
PVC coating.
Specification of 358 Security Mesh:
Mesh pattern:
76.2mm (3") x 12.7mm (0.5") welded at each intersection
Horizontal wires:
4mm diameter at 12.7mm
centres Vertical wires:
4mm diameter at 76.2mm
centres Weld strength:
75% of the minimum tensile strength of the wire Tensile range 540-690 N/m²
Wire Diameter:
3.25mm,4mm
Openings:
12.7x50.8mm,12.7x76.2mm
Fence Height:
1800,2000,2400,3000,4000,5200mm
Color:
Standard colours are Green and Black .
Other colours are available on request.
A> Securifor358 Hi-Security System
| Panels | Posts |
| Fence | Panel Size | section | O/A Length | Total number of fixings | |
| height | Height/Width | | | Inters- 1 Clamp bar | Corners- 2 Clamp bars | |
| m | mm | | | | |
| | | | | | | |
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 | |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 | |
| 3.0 | 2997 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 | |
| 3.3 | 3302 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 | |
| 3.6 | 3607 x 2515 | 100x60x3mm | 4500 | 13 | | |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | | 26 | |
| | | | | | | | |
B> Securifor 358 Maximum Security System
| Panels | Posts |
| Fence | Panel Size | section | O/A Length | Total number of fixings |
| height | Height/Width | | | Inters- 1 Clamp bar | Corners- 2 Clamp bars |
| m | mm | | | | |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
Advantages of 358 Mesh:
| Secure | - Anti-Cut
- Anti-Climb
- Internal Fixtures (Anti-Vandal) |
| Complete System | - Gates |
| Attractive Appearance | - Highly Transparent
- Arrow Straight Edges
- Flush Panel Finish
- Untidy Fixtures Hidden From Site
- Thoroughly Tested By CE & ISO9001:2008
- Large Variety Of Colours |
| Cost Effective | - Priced Competitively
- Virtually Maintenance Free |
| Durable | - Coatings Thoroughly Tested
- Large Variety of Coatings |
| Easily Installed | - Designed To Accomodate Ground Movement |
Application of 358 Security Mesh:
1. Industrial and commercial sites
2. Airports, railways, school, local authorities
3. Border and some other high safety requirement field.
4. Public utilities, military
5. Secure units AND prisons
