BTO-22 Galvanized Razor Barbed Wire for Protection Military Security Fence

Product Categories

Anping Yaqi Wire Mesh Co.,Ltd

Contact Now

BTO-22 Galvanized Razor Barbed Wire for Protection Military Security Fence

Brand Name : YQ

Model Number : YQ-J118

Certification : SGS, ISO9001:2008

Place of Origin : HEBEI,CHINA

MOQ : 1 TON

Price : USD630/TON-USD950/TON

Payment Terms : L/C, T/T, D/P, Western Union

Supply Ability : 500tons/month

Delivery Time : 7-15 days

Packaging Details : packed in waterproof paper

material : galvanized steel wire , galvanized metal strip

razor type : BTO-10 BTO-18, BTO-22 BTO-28 BTO-30,CBT-65

roll length stretch length : 8m, 10m, 15m, or as per customer request

roll weight : 6kgs, 6.5kgs, 7kgs, 8kgs, 10kgs, 15kgs, or as per customer request

roll diameter : 300mm, 420mm, 450mm, 500mm, 600mm, 730mm, 800mm, 900mm, 980mm, 1000mm, etc

surface treatment : electric galvanize, hot dip galvanized, powde coating

Usage : For military, for prison protection, For highway airport security fence etc

Core wire thickness : 2mm-2.2mm, 2.5mm-3mm

Zinc coating : 20g/m2, 50g/m2, 100g/m2, 150g/m2, 230g/m2

Contact Now

Hot Dip Galvanized Razor Barbed Wire BTO-22 For security with sgs certificate

Razor wire fence also named razor wire, razor barbed wire. concertinca razor wire fence, It is a new type of protection fence. With the character of beautiful, economical, secure fencing, construction of facilities, etc.

specification:
Material: High quality high carbon steel wire. steel strip
Blade: Galvanized steel.
Process: Galvanized - stamping.
Model: BTO-22, BTO-18,BTO-30,BTO-28, CBT-60. CBT-65,

core wire thickness: 2.0mm-2.2mm, 2.5mm-3.0mm
clipes: 3 clips or 5 clips

number of coils : 56 coils or as customer request
Roll diameter size: 30cm,40cm,45cm, 50cm,60cm, 70cm,80cm,90cm,100cm. etc.

Features: Razor barbed wire is a new developed fencing mesh which has the characteristics of a high security, artistic appearance, easily installed, economical and practical, anti-corrosion, anti-ageing, anti-solarization and durable.

Application: Widely used in military, field, prison, detention houses, government buildings and other national security facilities. Also fencing of residences, villa wall and windows, express way, railway, national border lines, etc.

Blade specification	Blade thickness	Cor. Wire diameter	Blade length	Blade width	Blade space
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	26±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28	0.5±0.05	2.5	28	15	45±1
BTO-30	0.5±0.05	2.5	30	18	45±1
CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

EX. dia	loops	Standard covering length	Production model	remarks
450mm	33	8m	CBT-65	Single coil
500mm	41	10m	CBT-65	Single coil
700mm	41	10m	CBT-65	Single coil
960mm	53	13m	CBT-65	Single coil
500mm	102	16m	BTO-12,18,22	Cross type
600mm	86	14m	BTO-12,18,22	Cross type
700mm	72	12m	BTO-12,18,22	Cross type
800mm	64	10m	BTO-12,18,22	Cross type
960mm	52	9m	BTO-12,18,22	Cross type

Material	Hot-dipped galvanized ,Stainless steel 304, stainless steel 430
Blade type	BTO-10, BTO-12, BTO-22,BTO-28,BTO-30,CBT-60,CBT-65
Roll diameter	450mm, 500mm, 600mm, 700mm, 730mm, 750mm, 800mm. 950mm , 1000mm and so on
Packing	Plastic weaving bags , pallets , carton box
Payment terms	30% advance , the balance 70% after receipt of copy of BL.
Remarks	Especial Size is customized as per client's requirement
