4 mm Wire Diameter Welded Wire Mesh Panel with 100 mm Mesh Size for Concrete
Product Introduction
Welded wire mesh panel is made with plain steel wire welded together in square opening.Then going through the hot-dipped zinc coating processs.It is made through the process of automation and sophisticated welding technique. The end product is level and flat, with sturdy structure and even strength throughout, the netting shows no wear and tear when cutting off a part or under a stress.
(1)Materials:Stainless steel wire, Low carbon steel wire, Galvanized wire
(2) Style:
Electro or Hot dipped galvanized after or before welding;
Stainless steel wire welded wire mesh;
PVC coated galvanized welded wire mesh;
Black wire/ without coated welded wire mesh.
Product Feature
1.Solid weldeding,uniform meshand flat surface.
2.Strong corrosion resistance,strong strength and strong protective ability.
3.Simple structure,extensive use,beautiful protactical,easy to transport.
4.Installation is not subject to topographic relief,especially for mountains,slopes and bends.
5.Low price and suitable for large area adoptions.
Product Specification
| Specification List of Welded Wire Mesh Panel |
| Opening | Wire Diameter |
| In inch | In metric unit(mm) | |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
| 1" x 1" | 25.4mmX25.4 | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
| 2" x 3" | 50mmx70mm | 2.0mm,2.5mm,1.65mm |
| 3" x 3" | 75mmx75mm | 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
| 2" x 4" | 50mmx100mm | 2.11mm,2.5mm |
| 4" x 4" | 100mmx100mm | 2.0mm,2.5mm |
| Technical Note: 1,Standard length: 1-8m; width: 0.5-3m
2,Special sizes available at request
3,Packing: in pallet. Custom packing available at request. |
Product Application
- Security fencing
- Security cages and frames
- Aviaries cages for birds
- Garden walls and trellis
- Dog Fences and enclosures
- Pond leaf protection covers
- Industrial fabrications
