Hot Dipped Galvanized Field Fence / Cattle Fence For Grassland In 2.2mm Diameter
Product Description of Field Fence
Field fence is also known as Prairie fence, Cattle fence, Grassland Fence, Horse Fence, Sheep Fence, Deer Fence, Woven Wire, Livestock Fence, Hinge Joint Field Fence which is made of hot-dipped galvanized steel wire, offer high strength and tensile strength, provide safety fencing against fierce striking of cattle, horse or goats. Knotted Wire Mesh Fences make an ideal fencing material for grasslands husbandry.
Class A: Hot dipped galvanized hinge joint field fece(zinc coated:220-260g/m2)
Class B: Hot dipped galvanized hinge joint field fence(zinc coated:60-70g/m2)
Class C: Electro galvanized hinge joint field fence(zinc coated:15-20g/m2)
*Material: low carbon steel wire(Q195), Tensile strength:550N/MM2
*Diameter of all wires used: Top / BOTTOM wire dia: 2.5MM-3.6mm
*Line /stay wire dia area: 1.7MM-2.5mm
*Top and Bottom wire diameter:2.0-3.2mm
*Hardness Mpa of all wires: according to consumer. (700-1400Mpa)
*Uprightness wire space: 5cm-60cm
*High area: 50cm-200cm
*Length for one rolls: 25m-200m
Product Specification of Field Fence
| No. | Specification of Field Fence | Weight | Bottom | Dia. |
| Type | Specification | kg | mm | mm |
| 1 | 7/150/813/50 | 102+114+127+140+152+178 | 20.8 | 2.5 | 2 |
| 2 | 8/150/813/50 | 89(75)+89+102+114+127+140+178 | 21.6 | 2.5 | 22 |
| 3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 22.6 | 2.5 | 22 |
| 4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 23.6 | 2.5 | 2 |
| 5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.9 | 2.5 | 2 |
| 6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 26 | 2.5 | 2 |
| 7 | 9/150/1245/50 | 102+114+127+140+140+152+178+203+229 | 27.3 | 2.5 | 2 |
| 8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 28.4 | 2.5 | 2 |
| 9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 30.8 | 2.5 | 2 |
| 10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 19.3 | 2.5 | 2 |
| Remark: Height of fence is from 0.8m up to 2.0m, length is 50m 100m or 200m per roll. Surface treatment can be made with electro galvanized or hot-dip galvanized, hot-dip galvanized cheap horse fence panels is much more durable. |
Product Features of Field Fence
1. Portable: easy fast to handle (set up, remove and put down), makes the fence panel very flexible.
2.Robust: interlocking system makes the fence very stable;
quality steel and fully welding makes the panel more stronger;
heavy duty and anti-broken;
high zinc or PVC coated make the fence durable
3. Environment Protection: connection with welded to bracket lugs and joining pins, no need to dig holes or lay foundations. And it benefit grassland protection.
4.Livestock Protection: no sharp edge, very smooth welding spot finihment.
5.Cost-effective: give your corral years of service and minimal maintenance at a low initial cost
Product Application of Field Fence
Poultry Equipment Glavanized Farm Fence/Field Fence/Lowes Hog Wire Fencing For page wire : Used as the fence of the horse ,sheep and goat , cattle and cow, pig , chicken ,deer and some other annimals.
